| DESCRIPTION | UNIT | VALUE | |
| Work table size (L x W) | mm | 1000*400 | |
| Max. vertical travel of table | mm | 1100 | |
| Max. distance from spindle center to work table | mm | 570 | |
| Max. horizontal travel of grinding head | mm | 450 | |
| Max. vertical travel of grinding head | mm | 400 | |
| The speed of longitudinal movement of the table | m/min | 45717 | |
| Automatic vertical stroke | mm | 0.005 | |
| Fast hoisting Electric Motor | Power | kW | 0.37 |
| Speed | rpm | 1440 | |
| Grinding wheel size | mm | 400*203*40 | |
| Grinding wheel speed | rpm | 1440 | |
| Motor power | kW | 11 | |
| Wheel spindle motor | kW | 45053 | |
| Pump motor | kW | 3 | |
| Work accuracy | mm | 0,015/1000 | |
| The maximum load on the table | kg | 450 | |
| Gross weight | kg | 4000 | |
| Packaging size (L x W x H) | mm | 3000*1775*2200 | |
