| DESCRIPTION | UNIT | VALUE |
| Maximum Laser power | W | 2000 |
| Processing scope | mm | 3000 х 1500 |
| Positioning accuracy | mm | ≤0,08 |
| Repeatable positioning accuracy | mm | ≤0,03 |
| Cutting head | Capacitive induction | |
| CNC system | Dedicated cutting software system | |
| Cutting head follow-up system | Capacitive high-speed automatic heightening | |
| XY Motion System | Gear and rack dual drive | |
| XY rail | SMG, JAPAN SH20/SH25 | |
| Servo motors | 3 x 850 Вт, 1 x 400 Вт | |
| Reducer | Flange type | |
| Machine tool structure | Gantry type, steel tube welded, dead weight 2T | |
| Computer | Industrial computer | |
| Cooling system | Integrated refrigerator, internal circulation of cooling water | |
| Working voltage | V, Hz | 3 Phase, 380V, 50Hz |
| Power consumption | kW | 17 |
| Cutting air pressure | mPa | ≥0,9 |
| Maximum speed | m/min | 100 |
| Overall size | m | 3,1 х 1,6 |
