4K, UHD 3840 x 2160 LED Display
Multi-touch up to 20 touchpoint
Dual System windows & Android build-in
Wide range of sizes 65″/75″/86″/98″
[divider height=”70″]
[divider height=”50″]
[divider height=”50″]
Wide range of sizes
Labotrix Touch S-Series comes in a wide range of sizes from 65″, 75″ to 86” to provide the right choice for any room, and ensures that everyone has excellent visibility, wherever seated.
Instant note-taking
Labotrix instant whiteboard software is integrated in the Android OS and allows you to make annotations and share them immediately without using another device.
Plug & play
Slide an OPS computer into the display and get started immediately.
Android on board
The Android OS has built-in apps such as a web browser, file explorer and documents editor. Browse the internet and open your MS Office or PDF files without running a computer.
Annotation overlay
Annotate over any word file, pdf file, image, site, app and save your notes in Labotrix Touch.
Infrared technology
This technology uses sensors in the full frame of the display to detect touches even if dust or other objects are obstructing portions of the frame.
[divider height=”50″]
[divider height=”20″]
Display Panel
Size: 86inch
Screen Size:1913.0(H) x 1084.0(V)
Backlight: LED Back Light Display
Aspect Ratio: 16:09
Panel Resolution: 3840 * 2160@60Hz
Brightness(nits): 400 cd/m²
Contrast Ratio: 4000 : 1 (Typ)
Viewing Angle: 178° / 178°
Response Time: 7ms
Supported Colors: 1.07 Billion Colors
Touch System
Touch Technology: Infrared ray shading detection system
Touch tool: Hand or the solid (soft tip) object
Touchpoints: 20 points
Read speed: More than 125 responses per second
Response time: 5 ms
Touch Resolution: 32768 x 32768
Light Resistance Capacity: 80K Lux
Glass: 4mm Tempered Anti-Glare Glass
Support OS: Android/Win7/Win8/Win10
Android
Android System: Android ™ Oreo 8
CPU/GPU: (2) ARM Cortex A73, (2) ARM Cortex A53 1.5 GHz
Core: 4-core
RAM: 2G
Internal memory: 64G
Refresh rate 60 Hz
Viewing angle 180
The response time for the screen 7 ms
Response time for interactivity 5 ms
Ambient light sensor Yes
A Wake-on-LAN Function Yes
Touch positioning accuracy 1 mm
Trajectory tracking speed 6 m / s
The ability to recognize touch with a pen and a hand Yes
The possibility of blocking a random touch Yes
Palm recognition function Yes
The ability to comment on top of any source Yes
I/O Port
Interface Front: Rear Ports: OPS Slot x 1 HDMI (2.0) input x 2, HDMI (2.0) Output x 1, USB-A 2.0 x 2 USB Touch (Type B) x 3 USB-A 3.0 (Fast Data transfer) x 2 LAN input x 1 LAN Output x 1 RS-232 x 1 DisplayPort x 1 VGA input x 1 VGA Audio input x 1 CVBS x 1 Mic (3.5 mm) input x 1 Headphone (Headphone) x 1
Front ports: HDMI (2.0) input (front) x 1 USB Touch (Type B) x 1 USB-A 3.0 (Fast data transfer) x 2 Sound: Built-in front speakers, 2 x 15 Watts
Accessories
Panel-1 piece; handles (without batteries and does not require power) – 4 pieces; sponge-1 piece; m6 mounting screws-4 pieces; mini PC mount with screws-1 piece; wall mount-1 piece; control panel-1 piece; AAA batteries-2 pieces; power cable 3m-1 piece; HDMI cable 3m-1 piece; USB cable 3m-1 piece; installation instructions-1 piece; user manual-1 piece
Working Environment
Power consumption 370 W during operation / 0.5 W in standby mode Operating conditions
Operating temperature 0° but 40°C
Storage temperature -15°, but 55°C
Working humidity 20%, but 80% humidity is non-condensing
Storage humidity 20% but 90% humidity without condensation Overall Dimensions 2000 x 1210 x 110 mm
Package dimensions 2100 x 1300 x 200 mm 82 kg
Package weight 110 kg
OPS Computer: (Optional)
CPU: Intel I5
Frequency 2.7GHz
Chipset H110
RAM 4G DDR3
Hard Disk: SSD 128G
Graphics card integration
WiFi Yes
Bluetooth Optional
Mirro-casting Device (Optional)
Function Miracast, Dlna, AirPlay / AirPlay mirror
Wireless Connection WIFI 802.11 b/g/n ac (2T2R)
Supported OS Android 4.1 Afterward; IOS 6.0 Afterward; Win 7 / 8.1 / 10 (Win7 Require Driver Software)
Supported Resolution 720 / 1080 P
The interactive dashboard comes with the “Interactive teachers software”.
Software Parameters:
Licensed Interactive Dashboard software (interface) in three languages: Kazakh, Russian and English. The software is designed to work with an interactive dashboard, and includes whiteboard tools, a driver, and an interactive application program. Interactive panel software: Operating modes: control (mouse), annotation, full screen, window, and transparent layer. Prepare and save lessons: rotate, move, and resize objects, including adding comments and creating screen snapshots; progressively reproduce actions on objects; automatic recognition and optimization of geometric shapes and polygons; adding hyperlinks to objects; making objects transparent; inserting templates and images as backgrounds and using a gallery; organizing pages; moving objects from page to page
attach files; save files in various formats (for example, PDF or HTML); save pages as separate image files (for example, JPEG or GIF); customize the grid on the page; insert Adobe ® Flash ® animation files from the gallery and add your own Flash files; a wide selection of drawing tools that differ in connection type, writing style, type of dotted lines, etc.; Display information with shadow and highlight effects. Curtain, spotlight, magnifier for magnifying individual areas. Access to most applications via the program control panel. Customize the palette of floating tools. Virtual tools for precise geometric operations: compasses, rulers, and protractors. Enter text from the on-screen keyboard. Automatic export to the Office format, to the website, automatic sending by e-mail.
