I. Working principle
UV sensor is a type of sensor that can use photosensitive elements to convert UV signals into measurable electrical signals through photovoltaic mode and photoconductive mode.
II. Specifications
Minimum wavelength: 300 nm.
Maximum sampling frequency: 1 Hz.
Slow response range:
0 – 500 mW/m2, resolution: <0.2 mW/m2
0 – 5 W/m2, resolution: <0.002 W/m2
0 – 50 W/m2, resolution: <0.02 W/m2
Fast response range:
0 – 500 mW/m2, resolution: <0.2 mW/m2
0 – 5 W/m2, resolution: <0.002 W/m2
0 – 50 W/m2, resolution: <0.02 W/m2
III. Structure and function
1. Comes with a 1.8-inch color LCD screen;
2. Equipped with 5 function buttons, the operation interface is simple and convenient;
3. Supports high-speed USB data channel, which can communicate with the data logger at high speed;
4. Support wireless communication with experimental terminals;
5. Built-in large-capacity removable battery;
6. Equipped with a hidden buckle sensor interface to support combined experiments with ordinary sensors;
7. Equipped with fixed position, fixed on the iron frame and combined with traditional equipment;
8. The sensor supports iOS, Android, windows and other systems.
IV. Typical applications
Can measure the intensity of ultraviolet rays.
V. Caution
This product is suitable for educational use only and is not suitable for industrial, medical, research, or commercial applications.
VI. Usage Tips
1. To use, the UV probe must be aligned with the light being measured.
